Inner Chamber	Stainless Steel 22 swg. 304 quality
External	Mild Steel Power Coated
Range	10°c to 60°c
Controller	Electronics Display Digital Temperature
Sensor	Controller : PT-100
Accuracy	+ / -0.5c
Uniformality	+ / -1.0'c
Compressor	Hermetically Sealed Brand New Kirloskar
Air Heater	Compressor : Special Type S. S. Tubular Air Heaters
Air Circulation	with fins : Forced air circulation from back well
Cool down time	45 min, upto 10'c without load from ambinet
Heat up time	30 min, upto 60°c without load from ambinet
DC Drive	Digital RPM Indicator Cum Controller
Shanking	Stroke length 25 mm (standard)
RPM	50 to 200 RPM
Lotus Clamps	S. S. Clamps having spring tension for holding flasks
Insulation	Puf Insulation
Door Gasket	Magnetic Gasket
Safety device	Thermostat
Electric requirements	AC 230 V & 50 Hz cycle

S.No.	CAPACITY
A	9 X 250 ml
B	16x 250 ml.
C	9 x 500 ml.
D	16 x 500 ml

For Growing Culture Of Micro Organism & Tissue Cell Approx Shaking Speed 20 To 200 Orbital Strokes Per Minute

Tray Size: 325x325 For 8 Flask (250 OR 500 ML) Size: 425xz425 For 16 Flasks (250 OR 500 ML) Provision Will Be Made For Accommodations Conical Flask Of Various Sizes

Optional Accessories:
Digital Rpm Indicator Various Clamp Size:100m1/ 250m1/ 500m1/ 1 Ltr.

Inner Chamber	Stainless Steel 22 swg. 304 quality
External	Mild Steel Power Coated
Range	5 C Above Ambient To 60° C
Controller	Electronics Display Digital Temperature
Sensor	PT-100
Accuracy	+/- 0.5° C
Uniformality	+/- 1.0° C
Air Heater	Special Type S. S. Tubular Air Heaters With Fins.
Air Circulation	Forced Air Circulation From Back Well.
Heat up time	30 min, upto 60°c without load from ambinet
DC Drive	Digital RPM Indicator Cum Controller
Shanking	Stroke Length 20 MM, 25 MM (standard) 40 MM
RPM	50 to 200 RPM
Lotus Clamps	S. S. Clamps Having Spring Tension For Holding Flasks
Insulation	Glass Wool
Door Gasket	Silicon Gasket
Electric requirements	Ac 230 V & 50 Hz Cycle.
