Applications

• Nutrients Like N, P, K, S, Ca, Mg, Zn, Cu, B, Mo, etc., in Agriculture Plants etc.
• Organic compounds in Biological matter.
• Glucose, Fructose, Carbohydrates, Proteins etc., in Foods.
• Edible dyes, alcohols etc., in Beverages.
• Purity of constituents in Pharmaceuticals.
• Toxic elements, Cd, Pb, Hg etc., in Effluents.
• Biological Samples.
• Constituents in compositions used in Metallurgy, Fertilizer, Pesticide, Chemical, Petro Chemical, Steel, Cement, Glass & Other Industries.

SPECIFICATIONS
SPECTRAL Range : 340-1000 nm Bandwidth : 5.0 nm Accuracy : ± 2.5 nm Readout : Graduated Scale Readability :2.5 nm Repeatability : ± 2.5 nm

PHOTOMETRIC

Range : 0-1.999 Abs Accuracy : ± 0.05 Abs. at 1.0 Abs Repeatability : ± 0.01 Abs. Stability (Baseline) : ± 0.01 Abs/hr. after 2hours warm up Stray light : < 0.5 % at 340 nm

LIGHT SOURCE : Tungsten (W) Halogen lamp
MONOCHROMATOR	Czerny-Turner with 600 lines/mm ruled Diffaction Grating
DETECTOR	Photo Diode
READOUT	3½ digit 7 segment LED of 12.7 mm height

READABILITY

0.1% T 0.001 Abs 1 unit conc

DETECTOR

Photodiode

POWER REQUIREMENT	230 V ± 10%,50 Hz, 10 Max. 60 VA
PHYSICAL DIMENSION	Size (W x D x H ) in mm Weight in kg 410 x 315 x 135 Approx. 9

ACCESSORIES SUPPLIED With Instruments At extra Cost
QUALITY STANDARD	ISO 9001 & CE
